drive shafts

at what size lift should they be replaced? and if you were going to do one at a time what one would you do first

Steel Blue 07 2dr
"Its the A.M bitches, its time for donuts!"
Jersey
..
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
..
Crew
dtcc687 is offline
Sponsored Links
Advertisement

post #2 of 10 Old 05-20-2011, 10:42 PM
Granite Guru

Join Date: Aug 2010
Posts: 148
Feedback: 0 reviews

I installed a Teraflex 2.5" coil 4dr kit on my 2010 2dr rubi 3 weeks ago and I just ordered a complete driveline package from Coast Driveline.

I have a vibration from my front driveshaft, I tried adjusting the lower control arms to less than factory specs and it drove like crap and vibration was still there! No torn boots or any signs of failure, just a bad vibration! took the shaft out smooth as glass!

I guess it just depends, I got over 3" of lift and do not have any heavy accessories.

I also have Teraflex monster track bars, front lower and rear upper control arms.

This lift is getting expensive, But Bill from Coast assures me my vibration will go away and I can go back to a normal caster range!


I never anticipated needing them so soon but it is what it is.....Flip a coin, No way to tell until after the install.
PmedicJ is offline
post #3 of 10 Old 05-20-2011, 11:32 PM
Rock God

jrider's Avatar

Join Date: Aug 2010
Location: Boise, ID
Age: 43
Posts: 1,195
Feedback: 1 reviews

I'm not sure if I got lucky or what but I have a TF 2.5 spring lift and when I installed my 5.38s they (4WP Denver) told me I would probably need a new front drive shaft or I would get vibration out of the front end. ??? "cause it's spinnin faster"??? Figured I would wait to see if I had any problems and I didn't so I'm still running stock shafts, no problems.
jrider is offline
Sponsored Links
Advertisement

post #4 of 10 Old 05-21-2011, 12:49 AM
Rock God

josh_jacklyn's Avatar

Join Date: Apr 2010
Location: TORNADO STRUCK-JOPLIN MO
Age: 34
Posts: 931
Garage
Feedback: 2 reviews

they say that anything with a 2.5 lift or higher you should replace the ds. i'm running a 3.5 rk lift and stock gears, frnt lower control arms and stock drive shaft as well and no vibrations ever! even when i had the 2.5 bb on there last year had no problems.

2011 MANGO TANGO sahara jku....bone stock.
r.i.p.08 jk x steel blue

CALL MARCUS.. NUFF' SAID..
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
josh_jacklyn is offline
post #5 of 10 Old 05-21-2011, 04:26 AM
JKO Addict!

unsub's Avatar

Join Date: Apr 2011
Posts: 3,512
Feedback: 1 reviews

Dustin Id replace the front first a lot of people tear the boot on the exhaust crossover pipe, and they go down hill from there.


To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
Official sponsor of the Jersey
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
Crew

To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.

"Wasn't Me I was in Sweetwater"
unsub is offline
post #6 of 10 Old 05-21-2011, 06:09 AM
JPK
Rock God

Join Date: Feb 2010
Location: Chevy Chase, MD
Age: 58
Posts: 606
Feedback: 0 reviews

I am still running stock shafts with an AEV 4.5" lift and 37's on a JKU. 20,000 lifted miles and going strong.

My Jeep has a Hemi and a 545rfe transmission as well as RROR skids, the different transmission and the RROR skids don't interfere with the front DS at full droop and cause boot tearing, whereas the oem 42rfe trans and the oem skid do, and sometimes the exhaust cross over as well.

If you don't tear the boot your oem shafts should be fine on a four door. In fact, the oem shafts are stonger than most aftermarket shafts because the rzeppa joint is stronger than the aftermaket u-joints. There will be less vibration with the oem shaft as well since the rzeppa is a true constant velocity joint.

If you do tear your front DS boot then it seems results vary widely, with some shafts lasting more than a year with a torn boot and some not lasting more than a month or so. As an alternative to a double cardin jointed shaft, you can send AEV your front drive shaft and the will modify it to make it thinner and (greasable too) to prevent auto trans/skid plate/exhaust interference while maintaining the rzeppa joint.

I have read that two doors with tall lifts reportedly need rear shafts because of length and angle issues.

JPK
JPK is offline
post #7 of 10 Old 05-21-2011, 06:40 AM
Rock God

AdamIsAdam's Avatar

Join Date: Nov 2008
Location: Long Island, NY
Posts: 1,025
Feedback: 1 reviews

I have 51k on my jk. About 30,000+ on my 2.5" TF coil lift. The front start boot on the drive shaft tore the first time I flexed it. I've been keeping it lubed manually ever since. So far do good...knock wood.


Sent from my EVO using Tapatalk

Adam
First Jeep:
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.

(heavily modded and wheeled!)
Last Jeep:
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.

Sunburst Orange
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.

Ordered 11/14/08
Shipped 11/25/08
Delivered 11/28/08

Mods:
Wrangler MT/R 35x12.5x15 on Soft 8's for the trails.
Duratrac 35" on Dick Cepek's for DD'ers.
5.13s, TF 2.5" Coil Lift, LCAs, & track bar, Mopar bumpers, WARN 9.5ti, diff covers, lots o' skids, EVAP relocated, breathers extended, ALLGIG, backup cam, Soundcoat Absorbtion Panels, and more...
AdamIsAdam is offline
post #8 of 10 Old 05-21-2011, 11:01 AM
JKO Addict!

e-jeep's Avatar

Join Date: Jan 2010
Location: Stuck walking up the down escalator
Posts: 5,713
Garage
Feedback: 12 reviews

Run the stock shaft till you need to change it unless the vibes are real bad. That said, it'll probably be my next mod even though I'm really not having any major issues.

My Build Thread ~
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.

NE Trail Ride Thread ~
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.

Want Jeep Mods? Marcus Has It!! ~ River City Offroad
Adrenaline Offroad
~ Best Jeep shop in the Washington DC area!![/COLOR]
e-jeep is offline
post #9 of 10 Old 05-21-2011, 12:26 PM
JKO Addict!

usmcdoc14's Avatar

Join Date: Oct 2007
Location: Norfawk, va
Posts: 3,881
Feedback: 1 reviews

when they die
plan on front dieing first
usmcdoc14 is offline
post #10 of 10 Old 05-22-2011, 12:57 AM
Official Monkey Business

TEXASKEV's Avatar

Join Date: Aug 2007
Location: Denton Tejas
Posts: 12,215
Garage
Feedback: 0 reviews
Send a message via AIM to TEXASKEV Send a message via Yahoo to TEXASKEV

For sure replace the rear first. I had a 4" Teraflex spring lift and had the rear fail at 70 mph on the hwy The front will get a ripped boot but that won't make it fail. Most of us spend at least 90% of our time on the street so the rear gets the workout. It will fail first in most cases.



All good now - JE Reel 1350 front & rear


08 2Door Red Rubicon. Rock Krawler 5.5 Longarm Coilover, Polly rear Coilovers. AEV hood & wheels, 37"KM2s, JE Reel 1350 shafts, 5.38 Yukon gears, Superior axles, Shrockworks stubby, Fab Fours rear, sPod, Rebel Offroad brakes, Warn winch and lots more.

To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.


To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.

Last edited by TEXASKEV; 05-22-2011 at 01:03 AM.
TEXASKEV is offline
