HIDprojectors install and review

EDIT!!!!! Well i guess webshots decided to change their format and i didnt log in in time to have my pictures transfered over to the new site so there all gone and i didnt save them on my computer or camera and hidprojectors wanted these test lights back so if you have any questions regarding install PM me and ill try to help the best i can. Sorry.
NEW EDIT!!!! i found the pic in my recycle bin, ill get them hosted again asap

Due to some cosmic stuff or maybe because the world is ending in december i was chosen (among some other fine members of this community) to do a "real world" test of some lighting choices for the JK. I picked the HIDprojectors setup for the JK. This write-up will show you how to install these from start to finish and in a few days include some pics of these vs stock headlights. HIDprojectors offers quite a few options of there system, including ballasts, bulb temp,painted housings,angel eyes, and led halos. My kit was the pre-assembled ones, you dont have to take your stock housings apart.

Heres what i recieved

The install is very easy you only need a few hand tools.
To start you need to remove your grill.
Remove the plastic screw clip things, i just pryed them out as unscrewing them didnt work.


next you just pull the grill off, there are a few clips along the bottom of the grill, then you take out the parking light bulbs, they just twist out of the housings. you can them remove the grill from the jeep and you end up with this


Next you need to remove the chrome ring that holds in the stock housing.
There are 4 torx screws holding the ring on, after the ring is removed you can pull out the housing.



To unplug the oem bulb there is a red tab you must slide out to be able to press the button on the harness to unplug it
heres the tab in the locked position


heres the tab in the unlocked position


After you unplugs the oem light you can remove the housing. After you remove the housing you remove the ring from the stock housing.


After you remove both housings your jeep should look like this


Now you get to start adding the new stuff.
First off you need to wire the lights, electrical noobs have no fear this is very easy and almost impossible to mess up.
First step is to connect the supplied harness to + terminal on your battery, the red ring terminal is the + one.


next there are 2 ground terminals one for each headlight harness. Just make sure there is no paint where the terminal is bolted to the body.
You can use a existing bolt (as i did) or make your own ground with a self tapping screw.


next is sorting out the wiring for each side. It is very easy as everything has matching plugs and cannot be plugged in wrong. You only need to plug in the HID harness to one of the factory headlight plugs.

'92 YJ
'13 WK2

Last edited by BeerMonkeY; 02-23-2013 at 06:26 AM.
BeerMonkeY is offline
Sponsored Links
Advertisement

post #2 of 52 Old 09-24-2012, 08:45 AM Thread Starter
JKO Addict!

BeerMonkeY's Avatar

Join Date: Sep 2007
Location: Lake Winola, PA
Age: 41
Posts: 6,283
Garage
Feedback: 0 reviews

After you plug in the one headlight plug to the HID harness you connect the rest of the peices
The HID harness plugs into the can bus canceller (these get rid of any flickering cause by the canbus system freaking out)
The canbus canceller them plug into the ballast, the other plugs on the ballast plug into the new hid projector.
this pic is of the drivers side harness (were still on the passenger side)


Now you need to get the HID blub harness into the headlight opening, you will see a small 2 wire plug that is not coming off the balast, this is the high beam plug.
Here it is circled


Next you need to run the wire over to the drivers side for that harness, heres how i ran mine.


I also taped up the unused drivers side factory headlight plug



You can make your own choice on where to put all the modules, heres where i put the ballast for the driver side, i put the other peice ubder the ballast


heres where i put the passenger side stuff

You will need to ground that harness as well, i just used the factory ground bolt on the drivers side fender (sorry no pic)
Then you get the wires out the headlight opening


Now you get to install the new housings.
Gather the light and the trim ring, plug in the 2 plugs for the projector and the smaller highbeam plug.
Now put the new housing in the bucket on the jeep
the new housings (like the orginal ones) have locating tabs that keep the lights where they should be


next put the trim ring over the light, Pay attention cause it only goes on one way.


Install both sides the same way, youy should end up with this


before i put the grill back on i checked they worked on high and low beam, all was good so the grill went back on the same it came off, just reverse




Stay tuned for comparison pics with oem headlights and my review on how they perform.

'92 YJ
'13 WK2

Last edited by BeerMonkeY; 09-24-2012 at 09:32 AM.
BeerMonkeY is offline
post #3 of 52 Old 09-24-2012, 08:46 AM Thread Starter
JKO Addict!

BeerMonkeY's Avatar

Join Date: Sep 2007
Location: Lake Winola, PA
Age: 41
Posts: 6,283
Garage
Feedback: 0 reviews

ok here are some nite shots alongside a stock headlight equipped 09. they were about 4 feet apart in the shots, my jeep is lifted 2" but was wearing the stock tires, his jeep is not lifted but had larger tires so headlight height should be almost the same. i aimed my lights myself i though they were a bit high but i dont get highbeamed at nite so i think there good.
now that i see the pics on a larger screen im not completly happy with them (the pics not the lights) i will try to get better ones asap
here are low beam side by side



HIDprojectors on low beam

oem headlights on low beam



HIDprojectors on high beam

oem headlights on highbeam


this is someone standing about 85 yards in the highbeams
HIDprojectors

oem highbeams

'92 YJ
'13 WK2

Last edited by BeerMonkeY; 10-04-2012 at 06:24 PM.
BeerMonkeY is offline
Sponsored Links
Advertisement

post #4 of 52 Old 09-24-2012, 08:47 AM Thread Starter
JKO Addict!

BeerMonkeY's Avatar

Join Date: Sep 2007
Location: Lake Winola, PA
Age: 41
Posts: 6,283
Garage
Feedback: 0 reviews

here is a few shots on a road
HIDprojectors on low beam

oem on low beam

HIDprojectors on highbeam

oem on highbeam

'92 YJ
'13 WK2

Last edited by BeerMonkeY; 10-04-2012 at 06:23 PM.
BeerMonkeY is offline
post #5 of 52 Old 09-24-2012, 08:47 AM Thread Starter
JKO Addict!

BeerMonkeY's Avatar

Join Date: Sep 2007
Location: Lake Winola, PA
Age: 41
Posts: 6,283
Garage
Feedback: 0 reviews

Here is my unbiased opinion on these lights
Install... very easy, i am a do it myself kinda guy as long as i have the tools to do it and i think even someone without a large tool collection or know how could do these (now i didnt assemble the projectors into the housings so this is not about that) the only odd tool that someone may not have it the torx needed to remove the lights and aim them but its a cheap tool to buy

performance... these lights blow the oem out of the water, the light is a bright white compaired to the yellow oem, you dont really think the oem are that yellow untill you see these. they dont really go further than the oem lights on highbeam but they light everything way better. the only odd thing that takes a little to get used to is the sharp cutoff on lowbeam but it doesnt take that long to get used to it. These lights seem to make things so much clearer at night. its really is (get ready for it) a night and day difference. i would recommend thses lights to anyone looking to upgrade from the crappy oem lights

problems/concerens
the passenger light has started to get some condensation inside of it but the weather here has been wack lately, 40's and 50's at night and 70's in the day. i know the lights have 2 breathers in them are sometimes covered with tape, i will check to see if the holes are covered and update this post

'92 YJ
'13 WK2

Last edited by BeerMonkeY; 10-04-2012 at 06:45 PM.
BeerMonkeY is offline
